Hybrid Welding Station

1 review Write a Review
      Call for Shipping Options (Commercial, Non-Rural addresses only)   Squeeze Type Resistance Spot Welder (STRSW) with single sided …
SKU: HWS
Weight: 725.00 LBS
Standard Equipment with Each Unit: EZ-Change High Force Pneumatic Handle (SA-50), Includes 3", 10", 20" & Wheel House Arms(SA-53, 54, 55 & 57) Replaceable Cap Electrode System; 10-Pack Assortment of Caps, 10' Air Cooled Leads, Built in Tool Storage
Optional Packages: SA-116 Single Sided Spot Welding Package: Includes Quick Spot Handle (SA-109), Quick Spot Electrode (SA-113)

Hybrid Welding Station

Product Details







Call for Shipping Options (Commercial, Non-Rural addresses only)



Squeeze Type Resistance Spot Welder (STRSW) with single sided spot welding capabilities.

This welder only requires 110 volt 20 AMP power source. (220 volt/480 3 phase power is NOT required)



Features Include:

  • Combination Transformer/Battery Operation
  • Direct Current Welding
  • 10 ft. Air Cooled Cables
  • Updated Digital Controls with Low Voltage Lock Out
  • Built in Tool Storage
  • Adjustable Tip Squeeze Force with up to 1120 lbs. of Squeeze Force
  • Approved for Boron Steel Applications
  • Used in I-CAR Training
  • 10,750 Amp DC Output @ 100% Duty Cycle (12,500 Amp maximum output)
  • Weld Cycle Time Adjustable up to 1600 ms.
  • Aluminum spot weld clamp accessory included on request

Product Showcase Brochure

  Note: Aluminum Spot Weld Package has been discontinued and not included with welder

(Fixed shipping applies to Retail purchases shipped to commercial addresses in the USA; additional costs my apply to liftgate required, rural, residential or export shipments)



Shipping & Returns

Customer reviews

1 Review Write a Reviews
  • Welding station
    5

    Posted by Unknown on 10th Mar 2013

    Product very well made and easy to use controls. I might reccommend locking caster at front wheels to prevent welder moving during operation eliminating possible vehicle damage.
